Rugged Servers (CC-RS Series)
MISSION-CRITICAL EDGE SERVER
CC-RS Series / AT3URDS
Intel® Xeon® Scalable / Xeon-E / Core™ i7/i9 | Up to 1.5 TB ECC DDR4 / 512GB DDR5 | Multi-Drive NVMe & 14 SATA Bays | MIL-STD-810G & JSS 55555
Form Factors:
19" Rackmount 2U, 3U, 4U, 5U & Console Mount
Processor Family:
Intel® Xeon® Scalable, Xeon-E / Silver 4410Y / Core i7 & i9
Redundant Power:
Dual Redundant 800W (DC/AC) / Up to 1500W (AC) Hot-Swap
Rugged Standard:
MIL-STD-810G/H, MIL-STD-461E/F, JSS 55555
KEY HIGHLIGHTS
- Enterprise Tactical Compute: Supports high-density Intel® Xeon® Scalable series, Xeon-E, Xeon Silver 4410Y (Intel C741 chipset), and Intel Core i7/i9 processors with scalable thermal margins up to 205W TDP.
- Massive Memory Architecture: Expandable memory architecture utilizing up to 12 ECC DIMMs across multi-channel configurations supporting 8GB, 64GB, 128GB, 512GB, up to an ultra-dense 1.5 TB DDR4/DDR5 ECC RAM.
- High-Capacity Storage & RAID: Scalable front-access hot-swap storage accommodating up to 14 SATA 6Gb/s SSD bays, internal dedicated 2.5" SSD bays (up to 8TB+), M.2 NVMe, and Hardware/Software RAID 0, 1, 5, 10 support.
- High-Speed PCIe Expansion & GPU: Up to 7 PCIe Gen 3 / Gen 4 slots with dedicated PCIe expansion kits supporting NVIDIA 4GB, 8GB, and 16GB high-performance GPU add-on cards.
- Multi-Gigabit & MIL Circular I/O: Configurable with dual Gigabit Ethernet, 10GbE SFP+ optical ports, and MIL-DTL-38999 circular defense connectors for USB, COM, LAN, and display.
- Defense-Grade Thermal & Electrical Architecture: Forced-air cooling with filtered ventilation, dual redundant power supplies (800W DC/AC to 1500W AC), compliant with MIL-STD-461F EMI/EMC and JSS 55555.
Technical Specifications
Complete Industrial & Defense Server SpecsSystem Board & Processing Core
Primary CPU:Intel® Xeon® Silver 4410Y Processor
Optional CPUs:Intel Xeon-E / Xeon Scalable (up to 28C/56T) / Core i7/i9
Core Performance:Clock rate up to 3.8 GHz, 38.5M Cache, up to 205W TDP
System Chipset:Intel® latest C741 Server Chipset
CPU Board Options:Active and Passive CPU board architecture flexibility
Operating System:Red Hat Linux Server / Windows Server / Ubuntu LTS
System Memory (RAM)
Standard Memory:128 GB High-Speed DDR5 ECC Registered
Memory Sockets:Up to 12 carefully optimized ECC DIMMs across 6 channels
Scalable Options:8GB, 16GB, 64GB, 128GB, 256GB, 512GB DDR4/DDR5
Maximum Expandability:Up to 1.5 TB DDR4-2666 / DDR5 Server-Class RAM
Drive Bays & Storage Architecture
Internal Storage Bays:(4) × 2 TB Enterprise SATA SSD
Empty Expansion Bays:2 × SSD Empty Drive Bays
Front Hot-Swap Bays:Extendable up to 14 SATA 6Gb/s front-access hot-swap bays
Optical Drive:1 × Slimline DVD-RW Drive
RAID Architecture:Software / Hardware RAID Levels 0, 1, 5, 10
Storage Scaling:1TB / 2TB / 4TB / 8TB SSD/HDD scalable configurations
Graphics & Expansion Slots
Standard Discrete GPU:NVIDIA 4GB Dedicated Add-On Card
GPU Upgrade Options:NVIDIA 8GB / 16GB Workstation/AI GPUs
PCIe Expansion:Up to 7 PCIe Gen 3 / Gen 4 Slots with high bandwidth
PCIe Expansion Kit:Supported for extra custom add-on telemetry / I/O cards
Rear I/O Interconnects & Networking
USB Ports:(2) × USB 2.0 MIL + (2) × USB 3.0 MIL
Gigabit Ethernet:(2) × GbE Ethernet Pin Type + (1) × RJ45 Port (MIL)
10G Optical Uplink:(1) × 10G SFP+ Rugged Connector
Serial COM:(1) × RS232 Serial MIL D-Sub / Circular Interface
Video Outputs:(1) × VGA, (1) × HDMI, (1) × DisplayPort (MIL)
SATA/600 Ports:SATA/600 with RAID Add-On-Card through SSD drive bay
Chassis Construction & Indicators
Chassis Material:Heavy-Duty Aircraft Aluminum Alloy HE30 / Steel
Form Factor / Size:19" × 3U × 550 mm (Optional 2U / 4U / 5U)
Weight:25 Kgs Maximum (Fully Integrated)
Cooling Method:Forced Air Cooling with high-reliability industrial fans
Status Indicators:Power, Heater & Drive Activity LEDs
Front Controls:Protected Front Bezel Power On / Off Switch
Power Supply & Redundancy
Standard Power Supply:230V AC 800 Watts Redundant Dual Module
Typical Power Usage:400 Watts Typical Operational Consumption
High-Load AC Option:Up to 1500W (AC) Dual Redundant Power Supply
DC Input Option:800W (DC) Redundant Dual Hot-Swap Power Units
Environmental & EMI/EMC Standards
Operating Temperature:-20°C to +55°C (Extended ranges available)
Relative Humidity:5% to 95%, Non-Condensing
Operating Altitude:Up to 10,000 feet Operational Support
Vibration & Shock:Tested & Certified as per JSS 55555 & MIL-STD-810G
EMI/EMC Standard:MIL-STD-461E / MIL-STD-461F Compliant
Radiated Emission / Suscep:RE101, RE102 / RS101, RS103
Conducted Emission / Suscep:CE101, CE102 / CS14, CS115, CS116
Target Deployments:
Military command shelters, airborne C4ISR systems, naval shipboard server racks, tactical mobile combat vehicles, radar telemetry processing, and mission-critical harsh industrial environments.
