13.3" Rugged Windows Tablet PC (CC133RTPC-U5)
NEXT-GEN AI-POWERED FIELD TABLET
CC133RTPC-U5
13.3" FHD (1920×1080) | Intel® Core™ Ultra 5 125U | 16GB RAM up to 48GB DDR5 | Dual Hot-Swap Battery Architecture
Processor:
Intel® Core™ Ultra 5 Processor 125U
Display & Touch:
13.3" TFT LCD (1920×1080) / 400 nits / ≥7H Glove & Wet Touch
Memory & Storage:
16GB (Up to 48GB DDR5) / 256GB (Up to 2TB M.2 SSD)
Durability & Ingress:
IP65 Waterproof / MIL-STD-810H / 1.22m Drop Resistance
KEY HIGHLIGHTS
- Intel Core Ultra 5 Processing Engine: Powered by the high-efficiency Intel® Core™ Ultra 5 125U processor with Intel® Graphics, optimized for intensive field computing, command telemetry, and AI acceleration.
- Armored 13.3" Full HD Display: 1920×1080 resolution panel featuring 400 nits brightness, protected by ≥7H surface hardness glass supporting both wet-hand touch and heavy glove operation.
- Hot-Swappable Dual Battery System: Incorporates an internal 300mAh safety bridge cell alongside a primary 8300mAh / 11.4V removable pack (≥6h runtime), ensuring true continuous zero-downtime hot-swapping in the field.
- Mission-Ready Field Connectivity: Factory integrated with true RS-232 COM (DB9), Gigabit RJ45 LAN, full-function USB 3.0 Type-C (data + charging), HDMI video out, and a 14-pin Pogo docking interface.
- Advanced Wireless & Data Capture: Equipped with cutting-edge Wi-Fi 6E, Bluetooth 5.3, multi-constellation GPS (Beidou/Galileo/GLONASS), 4G LTE, dual cameras (8MP Front / 12MP Rear), fingerprint reader, and optional NFC/UHF RFID/Barcode modules.
Technical Specifications
Complete Factory Hardware SpecsDisplay & Touch
Display Type:13.3" TFT LCD Panel
Resolution:1920 × 1080 Full HD
Aspect Ratio:16:9 Widescreen
Brightness:400 nits Industrial High-Bright
Touch Panel:10-Point Capacitive Touch Screen
Surface Hardness:Hardness ≥ 7H Scratch-Resistant Glass
Touch Capability:Supports Wet-Hand Touch & Glove Touch
Computing Engine & Storage
Processor (CPU):Intel® Core™ Ultra 5 Processor 125U
Graphics (GPU):Intel® Graphics Engine
System Memory:16GB DDR5 (Expandable up to 48GB)
Storage Drive:256GB M.2 SSD (Expandable up to 2TB)
Security Chip:Built-in Hardware TPM 2.0
Operating System:Windows 11 / Ubuntu 22.04.5
Wireless & Data Capture
Wi-Fi Interface:Wi-Fi 802.11 b/g/n/ax, Wi-Fi 6E Certified
Bluetooth:Bluetooth 5.3 (Data Range: 10m)
Cellular (WWAN):4G / LTE Multi-Band Module
Satellite GPS:GPS, Beidou, Galileo, GLONASS
Biometrics:Integrated Fingerprint Module
NFC Option:NFC Module (Optional)
Barcode Option:Barcode Scanner Module (Optional)
RFID Option:UHF RFID Module (Optional with custom cover)
Cameras, Audio & Controls
Front Camera:8.0 MP Fixed Focus Camera
Rear Camera:12.0 MP Autofocus with Flash (16MP opt.)
Audio Output:2 × 2W Built-in Waterproof Speakers
Microphone:1 × Built-in High-Sensitivity Microphone
Sensors:Integrated Hardware Gravity Sensor (G-Sensor)
Physical Keys:Power ×1, Brightness +/- ×2, Home ×1, Custom P1/P2 ×2
I/O Ports & Expansion
USB Type-C:1 × USB 3.0 Type-C (Data Transmission & Charging)
USB Type-A:1 × USB 3.0 Type-A, 2 × USB 2.0 Type-A
Network LAN:1 × 1GbE RJ45 Gigabit Ethernet Port
Serial COM Port:1 × RS-232 with DB9 (RS-422/485 opt.)
Video Out:1 × Full-Size Standard HDMI Port
Audio Jack:1 × 3.5mm Standard Headphone/Mic Jack
SIM Card Slot:1 × Nano SIM Card Slot
Storage Expansion:1 × TF Card Slot (Up to 256GB Expansion)
Docking Port:1 × 14-Pin Pogo Pin (USB Data & Charging)
Power DC Jack:1 × DC Plug (19V/3.42A 5.5mm/2.1mm)
Battery & Power Subsystem
Removable Battery:11.4V / 8300mAh Lithium-Ion (Hot-Swappable)
Built-in Battery:11.4V / 300mAh Lithium-Ion (Non-Removable Bridge)
Battery Runtime:≥ 6 Hours (1080P Video @ 50% Screen Brightness)
Bridge Battery Life:≥ 10 Minutes Runtime During Hot-Swap Operation
Power Adapter:19V / 3.42A, 65W DC Interface Adapter
Physical & Packaging Specs
Tablet Dimensions:345.0 × 233.0 × 35.2 mm (excluding handle)
Product Weight:2098g (excluding handle: ±10 g)
Package Box Size:434 × 255 × 60 mm
Box Gross Weight:3125g (Approx. 3.12 kg)
Chassis Color:Industrial Rugged Matte Black
Environmental & Reliability
IP Ingress Rating:IP65 Certified (Dust-Tight & Water-Resistant)
Drop Resistance:1.22 Meter Drop Resistance to Hard Surface
Military Standard:MIL-STD-810H Compliant
Certifications:CE / MIL-STD-810H
Operating Temp:-20°C ~ +60°C
Storage Temp:-30°C ~ +70°C
Relative Humidity:95% Non-Condensing
Warranty:2 Years Comprehensive Limited Warranty
Standard Included Packing List:
65W DC Power Adapter ×1, Industrial Stylus Pen ×1, Ergonomic Carry Handle ×1.
Downloads
Datasheet | 13.3" Rugged Windows Tablet PC (CC133RTPC-U5)
User Manual & Deployment Guide | CC133RTPC-U5 Ultra 5 Tablet Series
×
