6.56" Rugged Smartphone (CC-RP1)
INDUSTRIAL RUGGED HANDHELD
CC-RP1
6.56" HD IPS Display | MediaTek MT6789 Octa-Core | 8GB RAM + 128GB ROM | IP68 & MIL-STD-810H Certified
Model & Ref. No:
CC-RP1 (Ref. No. 2026090020954)
Processor Platform:
MediaTek MT6789 Octa-Core (Up to 2.2GHz)
Battery & Charging:
5,800mAh Polymer Li-Ion / 33W Fast Charging
Durability & Ingress:
IP68 Waterproof / 1.5m Drop Proof / MIL-STD-810H & CE
KEY HIGHLIGHTS
- Built for Extreme Demands: Driven by the MediaTek MT6789 Octa-Core processor (2×A76 2.2GHz + 6×A55 2.0GHz) with ARM G57 MC2 GPU and 8GB LPDDR4X RAM running Android 14 with GMS.
- 6.56" High-Brightness HD Screen: 720 × 1612 display delivering 670 Nits peak luminance for direct sunlight readability, PolyRainbow cover glass (>7H hardness), and wet-hand/glove touch response.
- High-Endurance Battery System: Integrated 3.85V / 5,800mAh polymer lithium-ion battery with 33W high-speed charging and dedicated Pogo Pin charging contact for uninterrupted shifts.
- Advanced Multi-Lens Imaging: Versatile setup featuring 48MP main camera with PDAF autofocus, 8MP wide-angle lens, 2MP macro camera with true flash, and a 32MP front selfie camera.
- Field Utility & Security: Equipped with dual custom programmable physical buttons, 1W flashlight, 2-in-1 power key fingerprint scanner, multi-protocol NFC, and 4G LTE dual-SIM connectivity.
- Certified Industrial Toughness: Reinforced metal + plastic structure delivering IP68 dust/water submersion sealing, 1.5m drop resistance, and MIL-STD-810H compliance.
Technical Specifications
Complete Factory Hardware SpecsProcessor, RAM & OS
Chipset:MediaTek MT6789
CPU Architecture:Octa-Core (2 × A76 2.2GHz + 6 × A55 2.0GHz)
GPU:ARM G57 MC2
Operating System:Android 14 with GMS
System RAM:8GB LPDDR4X
Internal Storage:128GB UFS2.2 (Optional 256GB Bulk)
Storage Expansion:1 × TF Card Slot
Display & Touch
Screen Size:6.56 Inch
Display Type:HD IPS / TFT Display
Resolution:720 × 1612 px
Brightness:670 Nits Sunlight Readable
Touch Panel:5-Point Capacitive Touch (Wet-Hand & Glove Support)
Glass Protection:PolyRainbow Cover, Hardness Above 7H (Scratch-Resistant)
Cameras, Flash & Sensors
Main Rear Camera:48.0 MP Autofocus with PDAF Support
Wide-Angle Camera:8.0 MP Wide-Angle Lens
Macro Camera:2.0 MP Macro Lens
Front Camera:32.0 MP Fixed Focus
Camera Flash:Integrated True Flash
Flashlight:Dedicated 1W Flashlight Torch
Sensors:Acceleration, Gravity, Light, Proximity, Geomagnetic, Gyro Sensor
Biometrics:Power On/Off & Fingerprint 2-in-1
Network & Wireless Connectivity
Cellular Technology:4G LTE Multi-Band Network Support
SIM Interface:4G+ Dual SIM (Micro SIM + TF / Micro SIM + Nano SIM)
Wi-Fi Connectivity:2.4G + 5.0G Dual-Band Wi-Fi
Bluetooth:Bluetooth 5.1
GNSS Navigation:GPS / BeiDou / Galileo / GLONASS, A-GPS
NFC Interface:ISO18092, ISO14443 A/B, ISO15693 & Mifare Support
Hardware Controls, I/O & Power
Custom Buttons:2 × Custom Programmable Physical Buttons
USB Interface:1 × USB Type-C
Charging Contacts:1 × Pogo Pin Dock Charging Interface
Audio Jack:1 × Dedicated Earphone Jack
Battery Pack:Built-in 3.85V / 5,800 mAh Polymer Li-Ion
Fast Charging:33W High-Speed Fast Charging
Environmental & Mechanical
Dimensions:170.2 × 80.7 × 14 mm
Product Weight:Approx. 311 g
Chassis Material:Industrial Reinforced Metal + Plastic
Color Options:Black / Black-Yellow / Black-Green
Ingress Protection:IP68 Dust & Water Submersion Proof
Drop Resistance:1.5 Meter Drop Resistance
Military Standard:MIL-STD-810H & CE Certified
Operating Temperature:-20°C to +60°C
Storage Temperature:-30°C to +70°C
Operating Humidity:95% RH Non-Condensing
Included Accessories:Power Adaptor × 1, Hand Strap, USB Cable × 1
Downloads
Datasheet | 6.56" Rugged Smartphone (CC-RP1)
